MBTL 180 Series Garbage Truck Lifters / Cart Tippers

Product Overview

Cart Compatibility

Domestic

Mounting Height

40-42

Application Types

Rear Load No Kick Bar

MBTL 180 Series Cart Lifter

The MBTL 180 takes one of the best selling, most dependable lifters from Bayne Premium Lift Systems and makes it even better. This lifter offers all the best characteristics of the original MBTL, like industry-leading ground clearance, solid hook drive mechanism, and no packer blade interference. However, with its improved dump height and depth, the MBTL 180 prevents spillage and increases route stops before cycling packer blade.

Powered by the patented Thinline^® rack-and-pinion rotary actuator for
smooth operation
Compatible with standard domestic style 2-bar roll-out carts
The solid hook drive mechanism automatically secures the cart to the lift plate
during the dump cycle
Over 19” of ground clearance reduces the risk of damaging the lifter on
uneven terrain
Sweeping motion for increased cart pick-up envelope
Will not interfere with packer panel when properly mounted
Powder-coated finish for durability
2-Year Limited Warranty

Specifications

Cart Compatibility
ANSI Z 245.60-2006 Type B Carts (domestic style 2-bar)
Lift Capacity
400 lbs @ 1600 psi
Hydraulic Pressures
Working Pressure – 1600 psi
Maximum Pressure – 2500 psi
Hydraulic Flow
2.0 – 2.5 gpm
Cycle Time
6 – 8 seconds
Bearings
Self-Lubricating Composite Material
Actuator
Patented Thinline® Rack-and-Pinion Rotary Actuator
Finish
Safety Yellow Powder-Coating
Options
• Tap-In-Kit • Mounting Plate Kit for Bolt-On Application • Commercial Container Bumper
