TASKMASTER HI-LIFT STATIONARY

Commercial and Industrial ProductsMobile Refuse Products

Cart Compatibility

Domestic

Mounting Height

48

Application Types

Compactor

C/I Taskmaster Series Cart Lifter

The C/I Taskmaster series from Bayne Premium Lift Systems offers an economical and safety- conscious solution for a wide variety of waste material handling applications. The C/I Taskmaster series combines our advanced line of cylinder lift products mounted on rigid steel frames. C/I Taskmaster cart lifters, or cart tippers, come standard with hydraulic power unit and electrical controls and are ideal for use with balers and compactors.

C/I Taskmaster Features

  • Compatible with standard domestic style 2-bar roll-out carts
  • Solid hook drive mechanism automatically secures the cart to the lift plate during the dump cycle
  • 230/460 volt 3-phase AC, 110/220 volt 1-phase AC and 12 volt DC self-contained hydraulic power units available
  • Cycle times as low as 8 seconds
  • Self-lubricating composite bearings at all pivot points eliminate the need for greasing
  • Powder-coated finish for durability
  • 1-Year Limited Warranty
  • Cart Compatibility

    C/I TSKM: ANSI Z245.60-2008 Type B Containers (domestic 2-bar carts)
    C/I HLIF: ANSI Z245.60-2008 Type B Containers (domestic 2-bar carts)
    C/I SHLF ANSI Z245.60-2008 Type B Containers (domestic 2-bar carts)
    Tilt Trucks with ANSI Standard 2-bar Configuration (up to 1yd. capacity)
  • Lift Capacity

    C/I TSKM: 550 lbs. @ 1800 psi
    C/I HLIF: 750 lbs. @ 2500 psi
    C/I SHLF: 1000 lbs. @ 2500 psi
  • Voltage (60 Hz)

    230/460 volt 3-phase AC
    110/220 volt 1-phase AC
    12 volt DC
  • Hydraulic Pressure

    2500 psi maximum
  • Hydraulic Flow

    1.8 gpm
  • Cycle Time

    8 seconds (C/I TSKM)
    12 seconds (C/I HLIF, C/I SHLF)
  • Bearings

    Self-Lubricating Composite Material
  • Finish

    Safety Yellow Powder Coating

Request Product Info
